Ventilator optimized for treatment of COVID-19 patients

Introducing the ELICIAE MV20, designed specifically for medical experts and patients fighting on the frontlines of the Covid-19 pandemic.

Simple to Use
ELICIAE MV20 is equipped with 3 main ventilation modes and high visibility LED numerial display, so that users with less experience can manage the settings easily and quickly.
Safe
Air flow through the ELICIAE MV20 system is stored in the gas scavenger system and is treated prior to discharge into the outside environment to minimize potential cross infection to other patients and medical personnel.
Low Cost
Conventional premium ventilators are equipped with complex ventilation modes, making them extremely costly; the ELICIAE MV20, with its carefully selected list of essential functions, is available for almost 1/10 of the price.
Mass Productive
ELICIAE MV20 is lightweight, designed using the best of Japanese engineering discipline in usability, testability, quality, and manufacturability and is optimized for high-quality mass production using the Technical Standards Foundation by Metran Japan. It has been fully tested for quality at all its production facilities, including Vietnam, to ensure the same high-quality standard.

RESPIRATORY VENTILATOR
ELICIAE MV20

  • Model of Ventilator ELICIAE MV20 Operation
  • Quick Start Guide
  • Specifications
Request Product Document

Technical Characteristics

Venturi Valve System*

ELICIAE MV20 utilizes a Venturi valve system, which allows it to operate in sync with the patient’s natural breathing cycle, significantly minimizing resistance pressure on patients with reduced and/or recovering pulmonary function.

*Venturi valve is a product resulting from Metran research, installed on a wide range of devices including the high-end high-frequency ventilators (HFO Humming II, HFO Humming V).

Pressure-Controlled Ventilation (PCV)

ELICIAE MV20 ventilator operates in time cycled pressure-controlled ventilation, in which inspiration airflow can be compensated by the Venturi valve during patient’s spontaneous breathing cycle. The function uses an established pressure level (peak inspiration pressure, PIP) and PEEP to provide a volume flow equal to the lung’s current tidal volume during each required inspiration cycle.

Heat and Moisture Exchangers (HME)

ELICIAE MV20 ventilation system combines heat and moisture exchangers with bacterial filters (HME) with a closed tracheal suction system to significantly reduce the chance of cross infection for patients and medical personnel.

Request Product Document
Connect with Sales

“We want to save lives”

Placing all other projects on hold, we committed all our resources into creating the Eliciae MV20.
